LQ40

METALIZED POLYESTER CAPACITORS | PHENOLIC TUBULAR

Features

  • ±20% Tolerance (Standard), ±10% optional
  • -40 to 65°C at full rated voltage
  • Insulation Resistance of 15 - 25k ΩF
  • 0.6% Dissipation Factor @ 1,000Hz
  • Tested 150% of Rated Voltage (1 min)
Download Datasheet 109-110.pdf

    Features

    • ±20% Tolerance1 (Standard), ±10% optional
    • -40 to 65°C at full rated voltage
    • Insulation Resistance of 15 - 25k ΩF
    • <0.6% Dissipation Factor @ 1,000Hz
    • Tested 150% of Rated Voltage (1 min)
    • 10k hours Reliability (65°C and 100% Rated Voltage)
    • ISO 9001:2015 Qualified Processes
    • Tested to MIL-STD-202
    • ROHS Compliance upon Request

    Suffix “V” is extended foil (non-inductively wound), providing soldered contacts thruout. These capacitors are useful when used as a filter in a power supply which has a very low current output, or if the capacitor must supply high surge currents.

    Suffix “Y” is the standard inserted tab construction for filter and bypass applications.


    ffj,f,ff,h,

    wsrgjetjmetyjm

    xcxx

    xc x

    xc.

    Bulk Discounts
    1 or above $5.00
    5 or above $4.90
    10 or above $4.75
    25 or above $4.50

    Variants List Header

    LQ40-103V
    10 $15.00 LQ40-103V
    LQ40-103Y
    - $15.00 LQ40-103Y
    LQ40-104V
    - $15.00 LQ40-104V
    LQ40-104Y
    - $15.00 LQ40-104Y
    LQ40-105V
    - $15.00 LQ40-105V
    LQ40-105Y
    - $15.00 LQ40-105Y
    LQ40-203V
    - $15.00 LQ40-203V
    LQ40-203Y
    - $15.00 LQ40-203Y
    LQ40-254V
    - $15.00 LQ40-254V
    LQ40-254Y
    - $15.00 LQ40-254Y
    LQ40-502V
    - $15.00 LQ40-502V
    LQ40-502Y
    - $15.00 LQ40-502Y
    LQ40-503V
    - $15.00 LQ40-503V
    LQ40-503Y
    - $15.00 LQ40-503Y
    LQ40-504V
    - $15.00 LQ40-504V
    LQ40-504Y
    - $15.00 LQ40-504Y
